Alux
84423N00
Outdoor / Ceiling Lights
Ceiling Downlights | 198-264 V AC /176-280 V DC
120 topLED 60 W DC - 64 W AC













IP | IP65 |
---|---|
IK | 10 |
Optic | Diffused |
Degrees | 121.8° |
CCT | 4000 K |
CRI | 80 |
Delivered lumens | 4202 lm |
Finishes | Anodized aluminum |
Installation position | Ceiling |
Control | |
Efficiency | 65.7 lm/W |
Source Type | topLED |
Technical description
Single emission ceiling downlights for outdoor application. The natural white LED light source with a diffused light distribution is composed of 120 powerled LEDs with CCT of 4000 K and a CRI 80; the source luminous flux is 9768 lm, with a 162.8 lm/W nominal luminous efficacy.
The device body is made of aluminium 6060 and features a anodised aluminum finish, processed by means of 20 µm anodizing; the diffuser is made of uv resistant polycarbonate. The ingress protection degree is IP65; the total weight is of 2.9 kg.
The total absorbed power is 64 W. The power supply cable is included and features a 1 m length.
The device features protection class I and can be ceiling-mounted.
Compliant with the EN 60598-1 standard and its specific provisions.
