Crew_2
8289
Indoor / Ceiling Lights, Pendant Lights, Wall Mounted Lights
Wall Lights - Ceiling Downlights - Pendant Luminaires | 220-240 V
1 topLED 11 W DC - 12 W AC
| IP | IP40 |
|---|---|
| Optic | Diffused |
| Degrees | 116.8° |
| CCT | 3000 K |
| CRI | 80 |
| Delivered lumens | 824 lm |
| Finishes | Green |
| Installation position | Wall lights, Ceiling |
| Control | |
| Efficiency | 68.7 lm/W |
| Source Type | topLED |
Technical description
Single emission wall lights, wall lights, ceiling downlights, pendant luminaires or pendant luminaires for indoor application. The warm white LED light source with a diffused light distribution is composed of 18 topled LEDs with CCT of 3000 K and a CRI 80; the source luminous flux is 1253 lm, with a 113.9 lm/W nominal luminous efficacy.
The device body is made of iron and features a green finish, processed by means of coating The device body is made of iron and features a sand finish, processed by means of coating; the diffuser is made of pmma. The ingress protection degree is IP40; the total weight is of 0.8 kg.
The total absorbed power is 12 W.
The device features protection class I and can be wall lights or ceiling-mounted.
Compliant with the EN 60598-1 standard and its specific provisions.
