Curvè LED
1144
Indoor / Wall Mounted Lights
Wall Lights | 220-240 V
4 topLED 24 W DC - 30 W AC
| IP | IP40 |
|---|---|
| Optic | Diffused |
| Degrees | 117.4° |
| CCT | 3000 K |
| CRI | 90 |
| Delivered lumens | 2211 lm |
| Finishes | Dark brown |
| Installation position | Wall lights |
| Control | |
| Efficiency | 73.7 lm/W |
| Source Type | topLED |
Technical description
Double emission wall lights for indoor application. The warm white LED light source with a diffused light distribution is composed of 72 topled LEDs with CCT of 3000 K and a CRI 90; the source luminous flux is 2980 lm, with a 124.2 lm/W nominal luminous efficacy.
The device body is made of aluminium and features a dark brown finish, processed by means of coating; the diffuser is made of pmma with a satin finishing treatment. The ingress protection degree is IP40; the total weight is of 1.490 kg.
The total absorbed power is 30 W.
The device features protection class I and can be wall lights-mounted.
Compliant with the EN 60598-1 standard and its specific provisions.
