Dama

9350

Indoor / Table and Floor Lamps

Table Lamps

1 topLED 1.8 W DC 5 V

IP
IP20
Optic
Diffused
Degrees
115.4°
CCT
3000 K
CRI
80
Delivered lumens
94 lm
Finishes
Light blue
Installation position
Floor
Control
Efficiency
52.2 lm/W
Source Type
topLED

Single emission table lamps for indoor application. The warm white LED light source with a diffused light distribution is composed of 1 topled LEDs with CCT of 3000 K and a CRI 80; the source luminous flux is 110 lm, with a 61.1 lm/W nominal luminous efficacy.

The device body is made of aluminium and features a azure ral 5024 finish, processed by means of coating; the diffuser is made of ABS with a satin finishing treatment. The ingress protection degree is IP20; the total weight is of 1.206 kg. The power supply driver is not provided and is to be ordered separately.

The total absorbed power is 1.8 W. The power supply cable is included and features a 0.15 m length.

The device features protection class III and can be floor-mounted.

Compliant with the EN 60598-1 standard and its specific provisions.

Downloads

Documentation

Data sheet

.pdf

Spares parts

.pdf

Instruction sheet

.pdf

General

.pdf

Product image

.jpeg

Specification text

.txt

Photometric data

2D/3D Drawings
