Ink system_SP
77597M20
Indoor / Catenary and Systems, Linear Lights
Systems - Lines
1 arrayLED 22 W DC 24 V
| IP | IP40 |
|---|---|
| Optic | Flood |
| Degrees | 20.6° |
| CCT | 2700 K |
| CRI | 90 |
| Delivered lumens | 1958 lm |
| Finishes | White |
| Installation position | Cable |
| Control | - |
| Efficiency | 89.0 lm/W |
| Source Type | arrayLED |
Technical description
Single emission systems or lines for indoor application. The super warm white LED light source with a flood light distribution is composed of 1 topled LEDs with CCT of 2700 K and a CRI 90; the source luminous flux is 2407 lm, with a 109.4 lm/W nominal luminous efficacy.
The device body is made of aluminium and features a white ral 9003 finish, processed by means of coating; the diffuser is made of pmma; the mounting frame is made of aluminium, with a white ral 9003 finish, processed by means of coating. The ingress protection degree is IP40; the total weight is of 0.820 kg.
The total absorbed power is 22 W.
The device features protection class III and can be cable-mounted.
Compliant with the EN 60598-1 standard and its specific provisions.
Electronics
Code 83042
Berda Maxi - DALI converter 1-144W DC stripLED - 12A 12V / 1-288 W DC stripLED - 12A 24V | 1-10V Push and Simply Dim Controller
| Family | Controller |
|---|---|
| IP | IP20 |
| Operation | CV |
Code 81417
Drivers On/Off remote - 180 W - Output 24 V - White | On/Off Driver 220~240V AC 180 W
| Family | On/Off Driver |
|---|---|
| IP | IP20 |
| Operation | CV |
Code 81416
Driver On/Off remote - 120 W - Output 24 V DC - White | On/Off Driver 220~240V AC 120 W
| Family | On/Off Driver |
|---|---|
| IP | IP20 |
| Operation | CV |
You've seen 3 products out of 3
