Lira_PB

9333

Outdoor / Ceiling Lights

Pendant Luminaires | 220-240 V

4 topLED 27 W DC - 31 W AC

IP
IP65
IK
10
Optic
Diffused
Degrees
130.6°
CCT
3000 K
CRI
80
Delivered lumens
1352 lm
Finishes
Black
Installation position
Ceiling
Control
Efficiency
43.6 lm/W
Source Type
topLED

Single emission pendant luminaires for outdoor application. The warm white LED light source with a diffused light distribution is composed of 1 topled LEDs with CCT of 3000 K and a CRI 80; the source luminous flux is 4136 lm, with a 153.2 lm/W nominal luminous efficacy.

The device body is made of stainless steel and features a black finish, processed by means of coating; the diffuser is made of pu; the mounting frame is made of stainless steel, with a black finish, processed by means of coating. The ingress protection degree is IP65; the total weight is of 2.955 kg.

The total absorbed power is 31 W. The power supply cable is included and features a 5 m length.

The device features protection class II and can be ceiling-mounted.

Compliant with the EN 60598-1 standard and its specific provisions.

Downloads

Documentation

Data sheet

.pdf

Spares parts

.pdf

Instruction sheet

.pdf

General

.pdf

Product image

.jpeg

Specification text

.txt

Photometric data

2D/3D Drawings
