Parker

84507N79

Outdoor / Bollards and poles, Lamp post heads

Bollard & Pole | 100-305 V AC /142-431 V DC

48 x powerLEDs 91 W DC - 100 W AC

IP
IP66
IK
08
Optic
Park
Degrees
129.4°
CCT
4000 K
CRI
70
Delivered lumens
13072 lm
Finishes
Grey
Installation position
Pole
Control
Efficiency
130.7 lm/W
Source Type
powerLEDs

Single emission bollard & pole for outdoor application. The natural white LED light source with a park light distribution is composed of 48 powerled LEDs with CCT of 4000 K and a CRI 70; the source luminous flux is 16134 lm, with a 177.3 lm/W nominal luminous efficacy.

The device body is made of die-cast aluminium en ab - 46100 and features a grey finish, processed by means of powder coating; the diffuser is made of extra clear glass with a silk-screening treatment. The ingress protection degree is IP66; the total weight is of 8.5 kg.

The total absorbed power is 100 W. The power supply cable is included and features a 1 m length.

The device features protection class I and can be pole-mounted.

Compliant with the EN 60598-1 standard and its specific provisions.

Downloads

Documentation

Data sheet

.pdf

Product image

.jpeg

Specification text

.txt

Photometric data

2D/3D Drawings
