Ribbon
C0045MDI05000
Indoor / Светодиодная Полоса
Светодиодная полоса | 1 topLED 60 W DC 24 V
12 W/m | 1278.8 Lm/m
| IP | IP20 |
|---|---|
| Оптика | Diffused |
| градус | 132.8° |
| CCT | 2700 K |
| CRI | 95 |
| Световой поток светильника | 6394 lm |
| Положение установки | Стена, Потолок |
| Управление | |
| Эффективность | 106.6 lm/W |
| Тип источника | topLED |
| List price (excl. VAT) | 98,00 € |
| Product category | A |
Техническое описание
Single emission led strip for indoor application. The super warm white LED light source with a diffused light distribution is composed of 800 stripled LEDs with CCT of 2700 K and a CRI 95; the source luminous flux is 6394 lm, with a 106.6 lm/W nominal luminous efficacy.
The device body is made of technopolymer and features a white finish.
The ingress protection degree is IP20; the total weight is of 0.36 kg. The power supply driver is not provided and is to be ordered separately.
The total absorbed power is 60 W The power supply cable is included and features a 0.2 m length.
The device features protection class III and can be wall lights or ceiling-mounted.
Compliant with the EN 60598-1 standard and its specific provisions.
